Featuring a 34.0cm³ professional grade engine, giving exceptional power to weight ratio.
Compact, ergonomic design
ECHO chain saws are all designed to the same professional standard, with no exceptions. Hard working, high quality with renowned Japanese build standards.
Ergonomic
Superbly balanced and lightweight making it ideal for a diverse range of jobs.
Product Details.
| CO² (g/kW・h) 1 | 1128 |
|---|---|
| Sound power level (dB(A)) | 106.6 |
| Sound pressure level (dB(A)) | 98.2 |
| Vibration Front handle/Rear handle (m/s²) | 4.1 / 6.8 |
| Applicable Bar Length (cm/inch) 2 | 30, 35 / 12, 14 |
| Chain Brake | Inertia |
| Chain Oil Tank Capacity | 0.260 |
| Chain Tensioner | Side |
| Choke w/ Automatic Fast Idle Release | Yes |
| Dry Weight (kg) | 4.0 |
| Engine displacement (cm³) | 30.5 |
| Fuel Consumption At Maximum Engine Power (L/h) | 0.68 |
| Fuel tank capacity (l) | 0.25 |
| Guide Bar Gauge (inch) | 0.043, 0.050 |
| Ignition System | CDI |
| Output (kw) | 1.1 |
| Output (ps) | 1.5 |
| Priming Pump | Yes |
| Saw Chain Pitch (inch) | 3/8 |
| Start Assist System | ES-start |
